XLR
3-pole XLR Connectors ( male & female )
HEAVY-DUTY WATERPROOF XLR CONNECTORS - IP66
Features
• IP66 Waterproof heavy-duty XLR connectors
• Can independently play the function of lP66 waterproof & dustproof
• Full metal solid structure housing for long life using & ensure excellent shielding effecto
• Unique creative waterproof system supply the reliable and durable waterproof effect
• Ergonomic oversize push button for comfortable plug & unplug
• Unique three-part design makes welding and assembling easier and faster
• Unique gear design makes assembling and disassembling easier
• Passed the testing of beyond 5000 mating cycles, due to made from high-qualityraw materials
• Passed SGS IP66 testing
• Invention patent protecting
Available Color Rings
Yellow-YL
Blue-BU
Green-GN
Red-RD
Purple-PL
Brown-BN
Grey-GY
Black-BK
Orange-OG
Engineering Drawing
Technical Data
| Title | RX3FWP | RX3MWP |
| Housing | Zinc alloy diecast | Zinc alloy diecast |
| Insert | PBT | PBT |
| Contacts | Bronze & Brass | Brass |
| Contacts plating | Gold | Gold |
| Strain-relief clamp | PA 10% GR | POM |
| Bushing | Zinc alloy diecast | Zinc alloy diecast |
| Coding ring | PA | PA |
| Order Code | Description | |
| RX3FWP-NG | 3 pole XLR female, Nickel plated housing, Gold plated contacts | |
| RX3FWP-BG | 3 pole XLR female, Black housing, Gold plated contacts | |
| RX3MWP-NG | 3 pole XLR male, Nickel plated housing, Gold plated contacts | |
| RX3MWP-BG | 3 pole XLR male, Black housing, Gold plated contacts | |
XLR FEMALE 3P
Features
• Ergonomic heavy duty design with Zinc alloy housing and PA 30% GR bushing
• Improved big button for latch lock
• ROXTONE brand engraved on the housing
• Replaceable color ring with a special strain-relief clamp for ease tightening the cable diameter from 3mm to 7mm
• Patent protected
Available Color Rings
Yellow-YL
Blue-BU
Green-GN
Red-RD
Purple-PL
Brown-BN
Grey-GY
Black-BK
Orange-OG
Engineering Drawing
Technical Data
| Title | RX3F | RX3M |
| Housing | Zinc alloy diecast | Zinc alloy diecast |
| Insert | PBT | PBT |
| Contacts | Bronze | Brass |
| Contacts plating | Tin or Gold | Tin or Gold |
| Strain-relief clamp | POM | POM |
| Bushing | PA 30% GR | PA 30% GR |
| Coding ring | PA6 30% GR | PA6 30% GR |
| Order Code | Description | |
| RX3F-NT | 3 pole XLR female, Nickel plated housing, Tin plated contacts | |
| RX3F-BG | 3 pole XLR female, Black housing, Gold plated contacts | |
| RX3M-NT | 3 pole XLR male, Nickel plated housing, Tin plated contacts | |
| RX3M-BG | 3 pole XLR male, Black housing, Gold plated contacts | |
XLR MALE 3P
Features
• Classic and simple design
• Heavy duty Zinc alloy housing and PA 30% GR bushing
• ROXTONE brand engraved on the housing
• Patent protected
Engineering Drawing
Technical Data
| Title | RX3FP | RX3MP |
| Housing | Zinc alloy diecast | Zinc alloy diecast |
| Insert | PBT | PBT |
| Contacts | Bronze | Brass |
| Contacts plating | Tin or Gold | Tin or Gold |
| Strain-relief clamp | POM | POM |
| Bushing | PA 30% GR | PA 30% GR |
| Order Code | Description | |
| RX3FP-NT | 3 pole XLR female, Nickel plated housing, Tin plated contacts | |
| RX3FP-BG | 3 pole XLR female, Black housing, Gold plated contacts | |
| RX3MP-NT | 3 pole XLR male, Nickel plated housing, Tin plated contacts | |
| RX3MP-BG | 3 pole XLR male, Black housing, Gold plated contacts | |
XLR FEMALE 3P
Features
• Ergonomic heavy duty design with Zinc alloy housing and PA 30% GR bushing
• Without locking “window” makes the housing more strength
• Special contacts pin with gear and fluting design to avoid moving
• ROXTONE brand lased on the housing
• Replaceable coding ring with a special strain-relief clamp for ease tightening the cable diameter from 3mm to 7mm
• Patent protected
Available Color Rings
XR-YL
XR-BU
XR-GN
XR-RD
XR-PL
XR-BN
XR-GY
XR-BK
XR-OG
Engineering Drawing
Technical Data
| Title | XF3 | XM3 |
| Housing | Zinc alloy diecast | Zinc alloy diecast |
| Insert | PA66 30% GR | PA66 30% GR |
| Contacts | Bronze | Brass |
| Contacts plating | Tin or Gold | Tin or Gold |
| Strain-relief clamp | POM | POM |
| Bushing | PA+TPE | PA+TPE |
| Coding ring | PA6 30% GR | PA6 30% GR |
| Order Code | Description | |
| XF3NT | 3 pole XLR female, Nickel plated housing, Tin plated contacts | |
| XF3BG | 3 pole XLR female, Black housing, Gold plated contacts | |
| XM3NT | 3 pole XLR male, Nickel plated housing, Tin plated contacts | |
| XM3BG | 3 pole XLR male, Black housing, Gold plated contacts | |
FAQ
1. You have different kinds of XLR?
Yes, we have different kinds of XLR, you can easily see the difference of their appearance, but actually they are different, you can choose the most suitable one you need.
2. Why you have different types?
To meet different demands.
RX3FWP-NG, RX3FWP-BG, RX3MWP-NG, RX3MWP-BG, they are the high quality version, with the function of waterproof, for special environment, and the cost is high.
XF3BG, XM3BG & RX3F-NT,RX3F-BG,RX3M-NT,RX3M-BG, they are the standard version XLR and positioned as high quality, when you have them on hand, you can feel their weight and excellent production technical.
RX3FP-NT, RX3FP-BG, RX3MP-NT, RX3MP-BG, they are the top seller version and cost-effective.
3. What's the differences of them?
RX3FWP-NG, RX3FWP-BG, RX3MWP-NG, RX3MWP-BG, they are IP67 waterproof heavy-duty XLR, play the function of waterproof & dustproof. Full metal solid structure housing for long time using & ensure excellent shielding, unique three-part design makes welding and assembling easier and faster, we have invention patent for them.
XF3BG, XM3BG & RX3F-NT,RX3F-BG,RX3M-NT,RX3M-BG, they are with standard XLR structure, which included bushing, housing, insert, strain-relief clamp, and color ring which for different usage definition.
RX3FP-NT, RX3FP-BG, RX3MP-NT, RX3MP-BG with simple design.
4. What are the materials of them?
RX3FWP-NG, RX3FWP-BG, RX3MWP-NG, RX3MWP-BG, the full metal version with zinc-alloy die cast, brass contacts, PPT 30% GR insert, PA 10% GR strain-relief clamp, PA coding ring.
XF3BG, XM3BG & RX3F-NT, RX3F-BG,RX3M-NT,RX3M-BG, zinc-alloy die cast housing, PA66 30% GR insert, bronze contacts, POM strain-relief clamp, PA 30% GR bushing and POM coding ring.
RX3FP-NT, RX3FP-BG, RX3MP-NT, RX3MP-BG, zinc-alloy die cast housing, PA66 30% GR insert, bronze contacts, POM strain-relief clamp, PA 30% GR bushing.
5. Do you have different finishing for them?
They have the housing with nickel plated or black finishing, and the contacts can be with tin or gold plated, the model with NG means nickel plated housing and gold pins, NT means nickel plated housing and tinned contacts, BG means black housing and gold pin.
6. They are all 3 pins, do you have other pins?
Yes, 5 pins or 7 pins are also available, you can contact with our sales.
7. What kinds of devices can use them?
The devices with XLR sockets can be used, like microphones, speakers, amplifiers, mixers etc.
8. How can I order them?
You can send email (sales@roxtone.com) to our sales, and order them by the MOQ of 1 master carton of them.
9. Can I custom-made them?
Sorry, they are engraved with Roxtone logo. More details, you can contact with us for further discussion.
