RAC3FCO-Power Link series power out connector
Features
• Lockable 3 pole equipment(AC) connectors
• Silver plated brass and brzone contacts supply excellent contact and conduction properties
• Replaceable color ring on connector indicates cable of different equipment or length easy for works
• Dust resistant bushing for longlife use
• Raw material according with UL-V0 for safe use
• 2 pieces strain-relief be provided for different cable diameter
• Patent protected
TPE Dust-proof structure
Available Color Rings
| Technical Data | |
| Housing | PA6 30% GR |
| Insert | PA66 20% GR |
| Latch | Zinc Alloy diecast |
| Unitary contacts | Brass |
| Contacts plating | Nickel or Silver |
| Strain relief | POM |
| Color ring | PA6 20% GR |
| Number of contacts | 3 |
| Rated current per contact | 20 A rms |
| Rate voltage | 250 V ac |
| Cable O.D. range | 6-12 mm |
| Fammability | UL V-0 |
Engineering Drawing
Application & Assembly Instruction
