SC215/220/225/240
Speaker cable
Applications
• Fixed installation in building services engineering
• Wiring of hi-fi system
Cable Colour
• Grey
Technical Data
| Order Code | SC215 | SC220 | SC225 | SC240 |
| Jacket, diameter | PVC 7.5 mm | PVC 8.0 mm | PVC 8.5 mm | PVC 10.2 mm |
| AWG | 16 | 14 | 14 | 12 |
| No. of inner conductors | 2 x 1.5 mm² | 2 x 2.0 mm² | 2 x 2.5 mm² | 2 x 4.0 mm² |
| Copper strand per conductor | 48 x 0.20 mm | 64 x 0.20 mm | 80 x 0.20 mm | 80 x 0.25 mm |
| Cond. insulation, diameter | PVC 2.8 mm | PVC 3.0 mm | PVC 3.2 mm | PVC 4.0 mm |
| Temperature range | min. -15 °C | min. -15 °C | min. -15 °C | min. -15 °C |
| Temperature range | max. +70 °C | max. +70 °C | max. +70 °C | max. +70 °C |
| Packaging | 100/300 m roll | 100/300 m roll | 100/300 m roll | 100/300 m roll |
Electrical Data
| Capac. cond./cond. per 1 m | 94 pF | 83 pF | 100 pF | 96 pF |
| Cond. resistance per 1 m | 12 mΩ | 7.3 mΩ | 2.4 mΩ | 4.3 mΩ |
