RA3DT-X5MXF
Roxtone Two Channel Stereo Isolator Set Unbalance to Balance
TWO CHANNEL STEREO ISOLATOR
Features
• Turns an unbalanced signal into a balanced signal, anti-interference, suitable for long distance transmission.
• Dual transformers ensure Hi-Fi audio signal 1:1.
• Eliminate the noise caused by AC and protect the equipment.
• Input and output patch cables are included.
• Packed in a dust-proof bag for perfect storage and carrying.
Unbalanced Input
Patch Cable 50cm
3.5mm stereo plug – XLR male 3-pole
Balanced Output
Patch Cable 15cm
XLR female 5-pole – 2 x XLR male 3-pole
Matching anti-shock and
dust-proof storage bag
Technical Data
| Title | ||
| Dimension | 7.3*2.5*3cm | |
| Input | 3PIN Stereo unbalanced signal | |
| Output | 5PIN Stereo balanced signal | |
| Impedance ratio | 600Ω: 600Ω | |
| Signal to Noise Ratio(1KHz 100mvrms) | 95dB | |
| Linear frequency response | 20Hz-20kHz | |
| THD+N | 0.05% | |
| Crosstalk | -75dB | |
| Order Code | Description | |
| RA3DT-X5MXF | Two Channel Stereo Isolator |
FAQ
1. Why do we need this isolator?
This isolator can convert unbalanced signals into balanced signals, which are also suitable for long-distance transmission, anti-interference. Moreover, it can eliminate the noise caused by AC and protect the equipment.
This makes it easy to interface professional audio gear with devices such as computer sound cards, iPods, mobile phone, or others.
2. Why did you use dual transformers? Are there any advantages?
Yes, dual transformers ensure Hi-Fi audio signal 1:1. In addition, the dual transformer can also easily convert unbalanced signal stereo input into balanced signal stereo output.
3. How about the Signal to Noise Ratio?
The Signal to Noise Ratio (1 KHz 100mvrms) is 95dB. You can find more parameters in the specifications.
4. Is this isolator sold as a whole set?
Yes! The whole set is included input and output patch cables, packed in a dust-proof bag for perfect storage and carrying.
5. What you required MOQ for them?
The MOQ for RA3DT-X5MXF is 24pcs.
6. If we want to put our own logo, can you do?
Sorry, we only sell it with Roxtone logo. But for special requirements, we can further discuss.
7. If I order them with MOQ, how many days can you finish them?
Normally we needs about 30 days for production except there are stocks. We will confirm with you after the order is confirmed.
8. How can I pay the order?
You only accept TT payment. More details, we can further discuss.
9. How about the warranty and return policy for them?
Roxtone products is warranted to be free of defects in material and workmanship for the lifetime warranty. We will repair or replace it upon inspection and at Roxtone’s discretion. This limited warranty is void of any defects are caused by mishandling, negligence or damage from user.
